Description

Eelectric galvanized wire binding wire production line

The construction galvanized wire binding wire production line can also be called  small electro galvanized wire production line, and the wire diameter is usually in the range of 0.6-1.2 mm. The finished wire is low in price, has good flexibility and is not easy to break. It is one of the most ideal binding wires in the construction industry, mainly using low-zinc cold-plated iron wire.

Eelectric galvanized wire binding wire production line Procedure:

gas flame heat treatment annealing–steel wire air cooling—steel wire air cooling–turbulent flow type smokeless cleaning–water cleaning–coating aid–drying–galvanizing–wire take up

Electric galvanized wire production line product description

Performance characteristics:Wire pay-off — — –Horizontal furnace annealing—– tasteless pickling – copper bar (take the cathode electric wire) — — — — — after four plating tank – zinc melting block adsorption to the wire surface brightness — — — — — the wire on the concentration of the brightener master — — — — — liquid recycling — — — — — – — clean water —-hot water washing — — – drying – — — — — — wire collection

Electric galvanized wire production line technical parameter

Production line design and manufacturing conditions

1, low carbon steel wire: according to the corresponding low carbon steel wire hot dip galvanized and zinc aluminum alloy standard provisions.

2, product specifications:  1.8 4.0 mm,

3. Tensile strength: low-carbon 400 N/mm2 ~ 550 N/mm2
4. Zinc layer thickness: galvanized 10-30 g /m2
5. Number of wires: 40
6. Heating energy: natural gas
7. Power requirements: 220~380V, 50HZ/60HZ
